D53 Electrical Connector Aluminum Bus Bar With 6061 Aluminum Material

Product Details:

Place of Origin:	Guangdong, China
Brand Name:	BG
Certification:	ISO9001, SGS
Model Number:	D53

Payment & Shipping Terms:

Minimum Order Quantity:	Negotiation
Price:	Negotiation
Packaging Details:	Standard export carton package
Delivery Time:	Negotiation
Payment Terms:	L/C, T/T
Supply Ability:	1000000 pcs

Contact Now

Detailed Product Description

Material:	6061 Aluminum	Size:	82904mm
Thickness:	4	Width:	90mm
Length:	82mm	Feature:	High Ampacity And Competitive Price
Finish:	Plate With Tin	Usage:	High Ampacity
Item:	D53
High Light:	high ampacity busbars , 6061 aluminum Bus Bar , 6061 aluminum bus bar in electrical

D53 Electrical connector aluminum bus bars high ampacity busbars with 6061 aluminum material

Details:

Material	6061 aluminum
Size	82904mm
Technology	Bending
Surface	Tin Plated
Usage	c
Advantage	high ampacity
Thickness.	4 mm
OEM	Acceptable

ALUMINUM BUS BARS FROM BAOGE MACHINERY MANUFACTURER

Baoge enables companies to fulfill their project requirements with a wide selection of excellent quality aluminum bus bar products. Aluminum is critical to a diverse range of applications in industries ranging from transportation, electronics, and construction, to packaging, household items, and recreational products.

Our aluminum bar products are available in various sizes, and we are also able to accommodate custom orders. Simply send us your component specifications, and we will be glad to help you bring your design to life.

At Baoge, quality is of utmost priority. All our locations carry ISO/9001 certification, and all employees undergo ongoing training to meet the exacting needs of our customers.

We are also committed to helping customers meet their deadlines. With our just in time delivery system and eight locations nationwide, we help customers maintain timely projects.

MORE INFORMATION ABOUT ALUMINUM BUS BARS:

Aluminum bus bars are often used as electrical conductors in power distribution systems, where heat can easily be dissipated. Because of the low value of the metal, it can be the best economic option for the application.

If requested, the moment a question or quote request comes to Storm Power, our engineering design team employs a process designed to make sure that each customer makes the right choice in metal, design and fabrication. If you need to create custom aluminum or copper bus bar, we work side-by-side with your engineers with the shared goal of making your part work from inception to completion.

Here are the factors Baoge Power employs in determining use of aluminum bus and electrical components:

Temperature Rise - Aluminum conducts at a lower level than copper. To compensate for heat dissipation, we will often recommend creating a larger surface area. This leads to better heat exchange for more efficient thermal dissipation.

Available Space - In tight enclosures - like cabinets, switchgear and panelboards - using a larger, thicker bus bar may seem an unlikely alternative, however, while dimensionally larger, the most commonly used 6101 aluminum alloy offers slightly more than half the conductivity (56%) at half the weight of copper. Installation is less of a burden when the aluminum bus is custom designed for a precise fit.

How and Where to Install - Industry standards provided by the Institute of Electrical and Electronics Engineers (IEEE), Underwriters Laboratory (UL) and the National Electrical Manufactures Association (NEMA) are applied by Storm Power to help to determine the feasibility of using aluminum connectors and bus systems. Experience and product knowledge are also applied by Storm's design engineers when recommending how and where to install aluminum.

Maintenance - Corrosion and regular expansion/contraction are the most common concerns for aluminum electrical connectors. In either case, periodic maintenance is necessary, as described below. Regular inspection and a torque schedule for bus bar fasteners is highly recommended. Environmental corrosion affects both copper and aluminum, especially in areas where hydrogen sulfide or extreme temperatures occur. At a microscopic perspective, these metals appear far different from the smooth surfaced bus bar seen by the human eye. Over time, corrosion can increase the severity of the imperfect surface, causing higher peaks and valleys. Silver or tin electroplating is a solution to this problem, and available in-house at Baoge.

PROCESSING TECHNOLOGY:

We support OEM service with high-precision CNC machining, cutting, wire cutting, turning, lathing, hobbing, milling, bending, twisting, punching, drilling, tapping, carving, twisting, riveting, electroplating, chemical plating and more; which are the bases of manufacturing copper parts in any customized shapes.

D53 Electrical Connector Aluminum Bus Bar With 6061 Aluminum Material 0

OUR PRODUCTION FACILITIES:

The wide range of products made of copper and other materials are processed by our powerful facilities:
Electric melting furnaces, large power extruders, rolling mills, drawing machines, lathes, CNC machining centers, dieing out pressers and punchers

D53 Electrical Connector Aluminum Bus Bar With 6061 Aluminum Material 1

QUALITY CONTROL:

In order to assure our customer the best quality of product, we are serious with quality control in every procedure. Here are some of equipment for different measurement purposes:

For chemical element and physical performance: spectrometer, tension strength tester and hardness meter.
For dimension and shape: coordinate measuring machine (CMM), optical profilometry, customized go/stop gauge and other basic tools such as vernier caliper, micrometer caliper and height gauge.

D53 Electrical Connector Aluminum Bus Bar With 6061 Aluminum Material 2

ORDER STEPS:

Contact us first. We would appreciate it if you could send us your drawing, detailed requirements or description of design.
Our engineers check your product design and emulate production, then send back production advice if there are something could be advanced.
Quotation and communication on other details.
Production and inspection.
Packing and shipment.
