Product Details:
Payment & Shipping Terms:
|
| Name: | Tin Plated Copper Sheet | Hole: | Multi Holes |
|---|---|---|---|
| Thickness:: | 2.0mm | Width:: | 165mm |
| Length:: | 275mm | Feature: | Excellent Electrical Conductivity |
| Finish: | Tin Plated | Size: | Custom |
| High Light: | tinned copper bus bar,tinned copper earth bar |
||
Multi Holes Tin Plated Copper Sheet / Custom Electrical Grade Copper Bar
Tin Plated Copper Sheet Introduction
Battery bus bar are often used as electrical conductors in power distribution systems, where heat can easily be dissipated. Because of the low value of the metal, it can be the best economic option for the application.
As with all custom components, the moment a question or quote request comes to RHI our engineering design team employs a process designed to make sure that each customer makes the right choice in metal, design and fabrication. Whether the choice is to shop online for Rectangular Aluminum Bar, to create custom aluminum or copper bus bar we work side-by-side with your engineers with the shared goal of making your part work from inception to completion.
Tin Plated Copper Sheet Application:
Electronic products, Children toys, Locks, Watches, Glasses, Baby carriage, Bicycle, Kitchen appliances, cameras, printers, office equipment, precision equipment and various kinds of vehicles.
| Product Name: Multi Holes Tin Plated Copper Sheet / Custom Electrical Grade Copper Bar |
| Thickness: 2.0mm |
| Width: 165mm |
| Length: 275mm |
| Feature: Multi Holes |
| Finish: Tin Plated |
| Custom:Yes |
Tin Plated Copper Sheet Technical Parameters:
| Thickness×Width (mm) | 1.5 -20× (15-500) |
| Copper content | 99.98% |
| Density (g/cm³) | 8.9 |
| Resistivity (Ωmm²/m) | 0.018 |
| Tensile Strength (MPa) | ≥250 |
| Elongation ( %) | 45-50% |
| melting Point | 1083℃ |
Conventional Types and Sizes:
| Types | Total Thickness | Thickness of copper | Width | Length | Weight(kg/m) |
| BG-1.0*550*650 | 1.0 | 0.3mm+0.3mm | 550 | 650 | 3.18 |
| BG-1.5*550*650 | 1.5 | 0.3mm+0.3mm | 550 | 650 | 4.77 |
| BG-6.0*268*333 | 6.0 | 0.3mm+0.3mm | 268 | 333 | 4.77 |
| BG-3 ×30 | 3 | 0.3mm+0.3mm | 30mm | ≤6000mm | 4.806 |
| BG-4 ×40 | 4 | 0.3mm+0.3mm | 40mm | ≤6000mm | 8.544 |
| BG-5 ×50 | 5 | 0.3mm+0.3mm | 50mm | ≤6000mm | 13.35 |
| BG-6 ×60 | 6 | 0.3mm+0.3mm | 60mm | ≤6000mm | 19.224 |
| BG-8*80 | 8 | 0.3mm+0.3mm | 80mm | ≤6000mm | 34.176 |
| BG-10*100 | 10 | 0.3mm+0.3mm | 100mm | ≤6000mm | 53.4 |
| BG-12*120 | 12 | 0.3mm+0.3mm | 120mm | ≤6000mm | 76.896 |
| Others | As request |
1. Different Material Support
Stainless Steel, Steel, Brass, Bronze, copper, Beryllium copper, Iron, Aluminum, Zinc, Zamak, ect.
2. Exquisite Processing
Stamping, CNC machining, casting, laser cutting, drilling, tapping, laser welding, butt welding, argon arc welding, CNC turning
surface grinder processing, cylindrical grinder processing
3. Multifarious Surface Treatment Provide
Sand blasting,Power coating,Painting,Anodization,Electrophoresis, Zinc/Chrome/Nickel plating,Black oxidation
4. Advance Equipment
CNC turning centers, CNC machining centers, Precision grinding machine, CNC milling machine, Swiss lathes,
Tapping machines, EDM wire cutting , drilling machine, 3-dimensional measuring instruments, projectors, test machine
5. Strick Inspection
All of our operations are strictly compliant with ISO 9001: 2008 guidelines. And During the process, we also have a series of inspection rule. Includes Incoming material inspection, Inspection of work-in-progress, Finished product inspection, Random warehouse inspections
Tin Plated Copper Bus Bar Pictures
